model: A430-HP
- Features
- Specifications
- Detailed Image
Detailed Product Information
• 3000kg lifting capacity
• AMGO exclusive hidden safety locks and manual single-point release
• Non-slip platform provides traction for the tires to stay put
• Dual safety devices: In case the primary safety locks are out of operation, the lift would also be locked automatically by a secondary safety device
• Multi safety locks in each column
• Adjustable lock ladder
• Portable: It can be moved easily by using the caster kits
• Warranty:
|
Model A430-HP |
|
4-Post Parking Lift |
|
Lifting Capacity |
|
3000kg |
|
Lifting Time |
|
37s |
|
Overall Length (Inc Ramps) |
A |
5008mm |
|
Outside edge of crossbeams |
B |
3987mm |
|
Overall Width |
C |
2409mm |
|
Width Between Posts |
D |
2167mm |
|
Max.Lifting Height |
E |
2202mm |
|
Max locking height |
2122mm |
|
|
Overall Height |
F |
2455mm |
|
Minimum Height |
G |
120mm |
|
Max.Underneath Height |
H |
2102mm |
|
Max. Lock Underneath runway |
2022mm |
|
|
Drive-Thru Clearance |
I |
1956mm |
|
Width Between Runways |
J |
940mm |
|
Outside Edge of Runways |
K |
1890mm |
|
Gross Weight |
|
690kg |
|
Motor |
|
3.0HP |
|
QTY of Container |
|
12Units/20'GP |
|
|
24Units/40'GP |
