model: A255 (5500KG)
- Features
- Specifications
- Detailed Image
Detailed Product Information
• Heavy duty design, lifting capacity: 5500KG;
• The floor plate's open top design allows it to lift various vehicles in low ceiling garages;
• 24V safe electrical control system, with high limit switch device;
• Revolutionary auto-activating double lock system;
• Exclusive feature: single-point manual safety lock device for simultaneous unlocking of both columns;
• Comes standard with 2 adjustable width settings;
• Extremely long four 3-stage arms are compatible with a variety of vehicles, from cars and Vans to light trucks ;
• Aero cables are used for synchronization;
• Self-lubricating UHMW polyethylene sliders and bronze bush;
• Dual chain-drive hydraulic cylinders, are designed and made on high standard utilizing high quality seals;
• Both single-screw rubber pads and saddle adapters are equipped as standard;
• Both 3” and 6” extension adapters are equipped as standard;
• Automatic arms restraints;
• Detachable foot guards and tool trays come standard.
|
Model A255 |
|
base plate chain-drived |
|
Lifting Capacity |
|
5500kg |
|
Lifting Time |
|
55s |
|
Max. Lifting height: (w/o extension adapter) |
A |
1850mm~1884mm |
|
Max. Lifting height: (w/ extension adapter) |
2079mm~2113mm |
|
|
Max. lock height: (w/o extension adapter) |
1790mm~1824mm |
|
|
Max. lock height: (w/ extension adapter) |
2019mm~2053mm |
|
|
Overall Height |
B |
3110mm |
|
Overall Width |
C |
3692/3829mm |
|
Drive-Thru Clearance |
D |
2673/2810mm |
|
Width Between Columns |
E |
3000/3137mm |
|
Minimum Pad Height |
F |
102mm |
|
Gross Weight |
|
996kg |
|
Motor |
|
3.0HP |
|
QTY of Container |
|
16 Units/20'GP |
|
Packing Dimension |
|
2950 X 540 X 1065 mm |
